Why OSVVM™?

Verification capability is largely a matter of programming. VHDL is a capable programming language. Like SystemVerilog, writing directly in VHDL is tedious and potentially error prone. Open Source VHDL Verification Methodology™ (OSVVM™) is VHDL’s answer to SystemVerilog’s UVM.

OSVVM is an advanced verification methodology that defines a VHDL verification framework, verification utility library, verification component library, scripting API, and co-simulation capability that simplifies your FPGA or ASIC verification project from start to finish. Using these libraries, you can create a simple, readable, and powerful testbench that is suitable for either low level unit tests or complex FPGA and ASIC tests.

OSVVM supports the same capabilities that other verification languages support – from transaction level modeling, to functional coverage and randomized test generation, to data structures, and to basic utilities. The intention of OSVVM goes beyond capability though – OSVVM intends to make verification environments easy, readable, and fun.



Capabilities of OSVVM

OSVVM is developed by the same VHDL experts who have helped develop VHDL standards. We have used our expert VHDL skills to create advanced verification capabilities that provide:

A structured transaction-based framework

• Suitable for all verification tasks – from Unit/RTL to full chip/system level tests.
• Similar block diagram to SystemVerilog + UVM, except It plugs together just like RTL
• Facilitates re-use of VC and test cases through all levels of testing (RTL to Full Chip)


Model Independent Transaction (MIT) Library

• Defines Transaction API – procedures called by test case to build up sequences of interface operations – such as send, get, write, read
• Defines Transaction Interface – connects Verification Component to Test Sequencer.
• Used by all OSVVM defined VC


Simplified Verification component (VC) development

• Uses MIT library = building block level re-use.
• Makes development of a VC as simple as writing a procedure.
• No OO or fork and join – uses natural concurrency of a VHDL entity/architecture
• Any VHDL engineer can do this


Readable Test cases

• Simplified since all VC of a similar type implement a subset of the MIT transaction calls (send, get, …)
• Directed tests or complex, randomized tests can be written by any VHDL engineer
• Readable and reviewable by the whole team including software and system engineers.


Unmatched Test Reports

• Build Summary – HTML (for humans) + JUnit XML (for CI tools)
• Test Cases – HTML
• Logs – HTML + plain text
• Requirements Tracking – HTML + CSV
• Helps Find and Debug issues faster


Powerful verification utilities that make VHDL a full verification language, including

• Constrained Random, Functional Coverage, Scoreboards, FIFOs, Memory Models, error logging and reporting (alerts), and message filtering (logs).
• Capabilities are simple to use, concise, and work like built-in language features.


Requirements Tracking

• Tracked using both OSVVM’s affirmations and functional coverage
• Tracks a count of each requirement and not just a boolean type check.


A Common Scripting API

• Same script runs all simulators – including GHDL, NVC, Aldec Riviera-PRO and ActiveHDL, Siemens Questa and ModelSim, Synopsys VCS, Cadence Xcelium, and Xilinx XSIM.
• Is an API on top of Tcl
• Most scripts are just slightly more than a list of files
• Can run Tcl when you need it – usually no Tcl is required


Free, Open Source Verification Components include

• AXI Full and Lite, AxiStream, Wishbone, UART, xMII, SPI, DpRam, VideoBus.


Co-simulation

• Supports running software (C++) in a hardware simulation environment.
• Write test cases in C++
• Run C++ models such as instruct set simulators


Architected by a long-time IEEE VHDL working group contributor

• So expect better VHDL implementations.


It is Free, Open Source under APACHE 2.0

• Upgrades an ordinary VHDL license to a full featured verification capabilities
• On GitHub and IEEE Open Source.
• We accept issues and pull requests on GitHub.
• Join us.


Get similar verification capabilities to SystemVerilog + UVM without needing OO.

While OSVVM work is not sponsored by ESA (because we are in the US), at SEFUW 2025 (ESA’s Space FPGA Users Workshop) an ESA representative said that they do not mandate which methodology to use, but instead suggest that you use one of the major ones, such as OSVVM, UVVM, SystemVerilog + UVM, or Cocotb.



Looking to improve your VHDL verification methodology? OSVVM provides a complete solution for VHDL ASIC or FPGA verification. There is no new language to learn. It is simple, powerful, and concise. Each piece can be used separately. Hence, you can learn and adopt pieces as you need them.



OSVVM Benefits

OSVVM demonstrates that you can have capability, simplicity, readability, and conciseness all from one language and methodology.

In OSVVM we code our verification components using familiar entities and architectures. Hence, the coding of these models can be either behavioral or RTL-like. With OSVVM, both test cases and verification components can be written by any VHDL engineer.

All OSVVM features are created in the free, open-source library. No special licensing beyond a VHDL simulator that supports VHDL-2008.



OSVVM Simulator Support

OSVVM is supported on Aldec’s Riviera-PRO and Active-HDL, Siemen’s QuestaSim and ModelSim, Synopsys VCS, Cadence Xcelium, GHDL (open source), and NVC (open source) simulators.



OSVVM Community

OSVVM is maintained by volunteers. In addition to using this methodology, you can contribute by providing feedback to make it better.

Help us create a thriving community by posting in our Forums.

Already using OSVVM. We can arrange for you to share your OSVVM story in our Blog
